Spiral-wound NF Membranes

Model:RS Series

RS series adopts special composite membrane, which can permeate monovalent salts and stop bivalent and multivalent salts, also stop the neutral molecules with 50~100 Dalton molecular weight. It is widely used for metal ions’ concentration, heavy metal rem

Consulting

Applications

It is mainly used in metal ions’ concentration, heavy metal removal, whey protein concentration, peptide concentration and the other small molecular materials. There are two kinds of appearances: FRP and sanitary grade. Sanitary grade NF membrane element

Membrane Models

Models	Specifications	Average Flow Rate gpd(m³/d)	Average Salt Rejection %	Download
RS10-35C	8040	7100（26.8）	99.0%
RS10-35F	8040	6900（26.0）	99.0%
RS10-50C	8040	5700（21.4）	99.0%
RS20-35C	8040	8400（31.8）	98.0%
RS20-35F	8040	8200（30.9）	98.0%
RS20-50C	8040	6800（25.4）	98.0%
RS30-35C	8040	11100（41.8）	96.0%
RS30-35F	8040	10800（40.7）	96.0%
RS30-50C	8040	8900（33.4）	96.0%
RS01-35C	4040	1700（6.4）	99.0%
RS01-35F	4040	1700（6.1）	99.0%
RS02-35C	4040	2000（7.5）	98.0%
RS02-35F	4040	2000（7.2）	98.0%
RS03-35C	4040	2700（9.9）	96.0%
RS03-35F	4040	2600（9.5）	96.0%

Notes: Due to technical improvements and product updates, models and specifications might be changed at any time. Please refer to the newest products' information.
